PM2-mini-1515
PM2-mini-1515 - Image 2
PM2-mini-1515 - Image 3

PM2-mini-1515

  • Portable Dot Pin Marking Machine
  • Battery Operated
  • Marking Area of 15mm x 15mm
  • Windows Based Software is included
  • App Based Software is also included, compatible with iOS and Android
  • Connects through local Wi-Fi or USB Cable (included)
  • High Quality Mark as small as 1mm
  • Can be equipped with Quick Change Base Plate for easier marking
Add to quote

Description

The PM2-mini-1515 is a portable, battery operated, dot pin marking machine. It can mark on everything from plastics to hardened metals up to 62 RC. With easy-to-use software compatible with Android and iOS you can get a clean and clear mark as small as 1mm, every time. Phone or tablet is independent of the unit for easier access to editing and less downtime. The PM2-mini’s updated standing design delivers a comfortable grip while maintaining the hammer-free experience. The ideal marker to mark single letters and 2D codes.

SketchbookDuo Windows Software Specs

Marking Methods MB mode [Push the start/stop button on the marking head to start] *Saving data even after the power off.
PC mode [Click the start icon on the PC to start]
Marking Force Setting 0 (no marking) – 99 (strong force)
Marking Speed Setting 1 (slow) – 99 (fast)
Default Font Setting MB font (original font)
MB font Elegant font (original font)
5×7 font (speed prioritized)
PC font (outline type)
Numbers of Characters in a Text Field Up to 50 characters (half-width alphanumeric characters)
Number of Text Fields in a File Up to 50 fields
Number of Files in the MB3 Controller Up to 255 files
Characters in 2D codes (DM, QR) 0-9, A-Z, a-z, and various symbols
Number of Characters in 2D codes (DM, QR) Up to 80 characters
Number of Serial Settings in a File Up to 4 serial settings
Number of Digits of Serial Characters Up to 8 digits, 1 – 99999999
Digits for Calendar Marking Year : 4, 2 or 1 digit(s)
Month : 2 or 1 digit(s)
Day : 2 or 1 digit(s)
Time : hour 2 digits, minutes 2 digits, seconds 2 digits
Julian date : 3 digits
Shift Marking 24 hours, up to 5 shifts
Number of Logos in the MB3 Controller Up to 31 logos
Convertible DXF Data Types Please note that this may vary depending on the CAD software and configuration
Types of Bitmap (BMP) Marking Fill
Outline
User-level Settings with Passwords Administrators (full functions)
Operators (limited functions)

Unit Specs

Marking Window 15x15mm(0.6×0.6″)
Power Supply AC adapter Input: AC100V-240V, 50/60Hz (120W
Lithium-ion battery 25.2V, 2.0Ah
Battery charger Input: AC100V-240V, 50/60Hz (120W
Weight
When using battery 2.3kg(4.4lbs)
Vibration Value 2.5m/s2 or less
Software App Wi-Fi
Windows software Wi-Fi, USB
Markable Materials Plastic to Metal (up to about HRC62) with standard pin. Optional high hardness pins available



SketchbookDuo App

Available for IOS and Android. New features include multiple line marking.
